Home>>SPEAKER CABINET>>Wooden Speaker Cabinet
WA Serie
Features :
WA serie is ecnomic two-way speaker system based on a heavy duty woofer and a tweeter mounted on a constant-directivity horn.
The light weight-yet-rugged, carpet-covered trapezoidal flakeboard enclosure with stand-mount cup facilitates portable use for live music or speech sound reinforcement and music playback.
Black powder-coated steel grille provides driver protection.
| Specifications: | ||||
| Model: | WA-10 | WA-12 | WA-15 | |
| System type: | 10" 2 Way | 12" 2 Way | 15" 2 Way | |
| Power handling: | 100W ,200W PEAK | 150W . 200W PEAK | 200W, 400W PEAK | |
| LF woofer: | 10"with1.5" voice coil | 12"with1.5"voice coil | 15"with 2"voice coil | |
| Tweeter: | Piezo tweeter | Piezo tweeter | Piezo tweeter | |
| Frequency response: | 45HZ-18KHz | 38Hz-19KHz | 35Hz-19KHz | |
| Impedance: | 8 Ohm | 8 Ohm | 8 Ohm | |
| Sensitivity: | 92dB | 94dB | 96dB | |
| Connectors: | 2*1/4 Jack input & 1*Speakon | 2*1/4 Jack input & 1*Speakon | 2*1/4 Jack input & 1*Speakon | |
| Dimension(W*L*H): | 35*37*59 CM | 40*37*66 CM | 47*44*70 CM | |
| Weight: | 10 KGS | 13 KGS | 16 KGS | |
| Model: | WA-215 | WA-15S | WA-18S | |
| System type: | Dual 15" 2 Way | 15"Subwoofer | 18" Subwoofer | |
| Power handling: | 400W, 800W PEAK | 300W, 600W PEAK | 400W, 800W PEAK | |
| LF woofer: | 2*15"with 2"voice coil | 15"with 3"voice coil | 18"with 4"voice coil | |
| Tweeter: | Piezo tweeter | |||
| Frequency response: | 35Hz-19KHz | 45Hz-1000Hz | 40Hz - 800Hz | |
| Impedance: | 4 Ohm | 8 Ohm | 8 Ohm | |
| Sensitivity: | 96dB | 97dB | 99dB | |
| Connectors: | 2*1/4 Jack input & 1*Speakon | 2*1/4 Jack input & 1*Speakon | 2*1/4 Jack input & 1*Speakon | |
| Dimension(W*L*H): | 49*46.5*110 CM | 50*54*64 CM | 54*60*69 CM | |
| Weight: | 34 KGS | 25 KGS | 31 KGS | |
